Resilient MountsVDM-M Series

[Translate to English:]

The VDM-M Series vibration damping mounts provide optimal performance in applications where damping and stability are absolutely necessary. The optimised stiffness level in the three directions ensures a high degree of vibration insulation and at the same time, the VDM-M Series is in position to absorb longitudinal loads. The insulation in vertical and lateral direction is achieved by low stiffness. The integrated limiter in the VDM-M Series provides fail-safe protection for mobile applications. This device limits vertical and lateral movements when the mounting is submitted to shock inputs. These mounts are suitable for a wide areas of applications ranging from the main drive on ships to generator set, pumps and compressors right up utility vehicles.


  • Anti-vibration mounts for generators offer optimal insulation from vibrations based on the stiffness characteristics.
  • Reliable with built-in centralized limiter.
  • Huge areas of application.

Technical Data

  • Nominal load range [kN]
    0.40 - 16.50 kN


Marine engines, pumps, ship drives, fans, compressors etc.
