Highly Flexible CouplingsRATO S/S+

[Translate to English:]

The highly flexible couplings RATO S and RATO S+ are torsionally flexible rubber couplings that compensates radial, axial and angular shaft displacements of the connected machinery. The torque is transmitted by elements loaded in shear. The different torsional stiffnesses and damping factors available provide the possibility to satisfactorily tune the torsional vibration behaviour of the drive system. The essential parts of the coupling are: the torsional flexible element, the membrane package to absorb the axial and angular displacements and the connecting parts to the drive and driven machinery.


  • Easy and quick installation of the high torque flexible coupling thanks to the segmented design with reduced weights of the individual segments
  • The segments are arranged for maximum thermal load and therefore long service life of the system
  • Compact torsionally couplings with an internal hub for space-conserving and weightsaving drive dimensions in order to cut down on the project costs
  • With the introduction of the ACOTEC range, smaller sizes with higher power density provide good price/performance ratio.

Technical Data

  • Torque Range TKN [kNm]
    12.50 kNm - 800.00 kNm
  • Speed range [1/min]
    500.00 RPM - 2,100.00 RPM


Flexibly mounted engines and rigidly mounted engines.
