The new VULKAN N-Flex® drive shaft is based on the patented NEMOS technology featuring a design consisting of fiber-reinforced composite and elastomer material. It offers a unique combination of torsional elasticity and high displacement capacity in one single component. The N-Flex® combines the functions of elastic couplings and drive shafts, reducing the number of components and mass of the driveline.
Technology: Unidirectional glass fibers are arranged in two layers of composite coils, transmitting the torque of the drive train. The outer set of coils is purely tension-loaded while the inner coils are compression-loaded, resulting in radial and axial equilibrium of forces. The composite coils of each layer are decoupled by gaps, the outer and inner layer are decoupled by high-performance elastomer material. This allows the coils to remain bending compliant which enables the entire shaft to be flexible in multiple directions. Additionally, the decoupling induces a virtually unidirectional transmission of the torque through the composite coils which means that high strains can be applied resulting in an excellent torsional elasticity of the N-Flex® drive shaft.
Get in touch to find out how N‑Flex drive shafts can be implemented and improve your application.
- High torsional elasticity
- High flexibility in axial, radial, and angular direction
- Maintenance free
- Good structure-borne noise isolation
- Weight reduction
- Low reaction forces
- Corrosion resistant
- Long unsupported shafts
- Customized design possible
